HHHP-HE
Inverter High Efficiency Split Systems with High Static Horizontal Soffit Mount Fan Coils. Available ESP up to 0.80″. Efficiencies up to 20.00 SEER2 and 13.3 EER2.
Specification Sheet
Typical installations for the HHHP-HE include:
- Apartments
- Condominiums
- Independent Care Facilities
- Pre-Manufactured Homes
- Single Family Homes
- Modular Buildings
- Student Housing
- Offices
- Stores
Features:
Highly Efficient/ High Performance
- Highly Efficient Inverter Compressor, with Efficiencies up to 20.00 SEER2
- Air Handlers EC Blower Motor, with Available ESP up to 0.80″ WC
- Low Amp Draw DC motor in Outdoor HP
Quite Operation , Inside and Outside
- Low Sone DC motor in HHHP Fan Coil
- Quite Inverter Compressor in Outdoor Heat Pump, with low Sound Levels
Heating at Low Ambient Conditions
- Standard Base Pan Heaters
- Crankcase Heater
Design
- Standard Rear Return Air or Optional Bottom Return Air
- Installed Indoor Fan Coil Freeze Protector
- Automatic Restart Function
- Available Optional 24V Control Interface for use with 3 rd Party Thermostats
- Liquid Line Service Port
- External Condensate Pump (9-18) or installed Condensate Pump (24-60)
- Cleanable Filters in Fan Coil
- Gold Pre-Coated Fins on Evaporator and Condenser Coils
- Compressor Time Delay
- Compressor Overload and Over Current Protection
- Environmentally Friendly R454B Refrigerant
- Factory Installed R454B Refrigerant Leak Sensor
